2. Extra cost is necessary if packed by wooden case
| Machine Type: | LAMINATING MACHINE | Video Outgoing-inspection: | Provided |
|---|---|---|---|
| Machinery Test Report: | Not Available | Core Components: | PLC, Gearbox, Motor, Pressure Vessel |
| Warranty: | 1 Year | Weight (kg): | 1800 |
| Power (kw): | 15 | Key Selling Points: | Semi-Auto |
| Product Name: | Sticking Paper PVC Laminating Machine | Glue: | White Latex, Solvent Glue ,PVAC ,PO ,PU |
| Covering Film: | PVC ,Paper ,Veneer,PE | Base Profiles: | MDF/WPC ,PVC ,Solid Wood ,partial Board ,Aluminum ,Steel, Marbles |
| Voltage: | AS Request | Structure Size: | According To Customer Requirements |
| Working Speed: | 3-8m/min(Adjustable Speed) | Gluing Way: | Roller Spreading Glue |
| Max.working Width: | 1300mm | Max.working Height: | 45mm |
Main technology parameter  | ||
Mode specification  | φ190-1350mm  | |
Board length  | Above 600mm  | |
Board width  | 1220mm  | |
Board thickness  | 1.5-30mm  | |
Rate of material delivery  | 5-25m/min  | |
Motivity power  | 8kw  | |
Heating power  | 20kw  | |
Machine weight  | around 4000kgs  | |
Paper width  | 1280mm  | |
Structure size  | 18000*2000*1800mm  | |
Principal axis roller diameter  | φ190  | |
Roller specification  | diameter 190 x L 1350mm  | |
Max. covering Film Width  | 1280mm  | |
Panel thickness:  | 3-45mm  | |
Panel sizes  | 1220 *2440mm  | |
machine speed  | 1~20m/min.  | |
Min. processing panel length  | 500mm  | |
TC Machinery Company Factory Price High Speed Woodworking Machinery Pvc Foil Laminating Machine
TC Multifunctional Semi-automatic PU Paper Cold Glue Laminating Machine for Wood Based Panels
